Ricoh SR4120 - Upper Tray; End Fence (SR4130)

1.Replacement and Adjustment
12
Upper Tray
1. Upper tray [A] ( x 1)
End Fence (SR4130)
1. Remove the rear upper cover. Rear Upper Cover, Rear Lower Cover, Upper Cover
2. Support the upper tray [A] with your right hand, and then pull gear [B] toward you to release.
3. Upper tray [A] ( x 1)
4. Lower Tray (Lower Tray)
