Ricoh SR4120 - Paper Exit Gate Motor; Leading Edge Guide Motor

1.Replacement and Adjustment
24
14. Remove the corner stapling unit [A] from between the front and left plates.
Paper Exit Gate Motor
1. Corner stapling unit (Corner Stapling Unit)
2. Stapler bracket [A] ( x 3, x 1)
3. Paper exit gate motor [A] ( x 2, x 1)
Leading Edge Guide Motor
1. Corner stapling unit (Corner Stapling Unit)
