Ricoh SR4120 - Paper Guide Motor

1.Replacement and Adjustment
61
Paper Guide Motor
1. Remove the paper guide unit. Paper Guide Unit
2. Disconnect the sensor bracket so that you can access the screw below.
3. Disconnect the motor.
4. Separate the unit from the motor.
