2. Detailed Descriptions
Overview
Layout
General Layout
No. Name No. Name
1 Punch Units 5 Corner Stapler
2 Side-to-Side Fold Roller 6 Shift Tray
3 Booklet Stapler 7 Proof Tray
4 Booklet Staple Tray - -
• When pushing the booklet stapler unit into the finisher, make sure that the unit is against the frame, as
shown in the blue circle, and that jam release lever R8 is closed completely.
