Ricoh SR4120 - Corner Stapling

2.Detailed Descriptions
77
[C] detects the end of the paper stacking holder [B]).
Corner Stapling
Components
No. Name No. Name
A Positioning Roller Lift Motor E Drag Roller
B Positioning Roller F Stapler
C Exit Motor G Stapler HP Sensor
D Stapler Movement Motor H Positioning Roller HP Sensor
