Ricoh SR4120 - Stacking Roller HP Sensor

1.Replacement and Adjustment
30
2. Stapler bracket [A] ( x 3, x 1)
3. Turn back the stapler bracket, and remove the trailing edge pressure plate HP sensor bracket [A]. ( x 1)
4. Trailing edge pressure plate HP sensor [A] ( x 1)
Stacking Roller HP Sensor
1. Corner stapling unit (Corner Stapling Unit)
