9.1 Operation in the Chart Screen
Groups Items Functions
Zoom Enlarges a part of a figure
Pan Enlarges the part near the cursor
Screen
Reset
Restores the original size
Linear Linear display of X-ray intensity
Square root Square-root-axis display of X-ray intensity
Display of the
vertical axis
Logarithm
Log display of X-ray intensity
Fig. 9-1-1 Chart Screen
