RIGOL Chapter 6 Operations and Measurements
6-44 MSO5000 User Guide
5. Set the Horizontal/Vertical Measurement Unit
⚫ When "X" is selected under Select, you can set the horizontal measurement
unit. When the source can be Math1-Math4, this menu is grayed out and
disabled.
Press More → Hori. Unit, and rotate the multifunction knob to select
the horizontal measurement unit. Then press down the knob to select it. You
can also press Hori. Unit continuously or enable the touch screen to select
it. The available units include "s", "Hz", "Degree(°)", and "Percent(%)".
➢ s: measures the time value at X Cursor (taking the trigger position as
reference). The measurement results include AX, BX, △X, and 1/△X.
Wherein, AX, BX, and △X all indicate time, and 1/△X indicates
frequency.
➢ Hz: measures the frequency value at X Cursor (taking the trigger
position as reference). The measurement results include AX, BX, △X,
and 1/△X. Wherein, AX, BX, and △X all indicate frequency, and 1/△X
indicates time.
➢ Degree(°): measures the phase value at X Cursor. The measurement
results include AX, BX, and △X, and they are all expressed in degree.
This oscilloscope allows you to set the reference position for the phase
according to your needs. After adjusting X Cursor to a desired position,
press Set Reference to take the current cursor position as the
reference. The current positions of Cursor A and Cursor B are
respectively defined as "0°" and "360°". Meanwhile, two vertical
cursors (in blue) that cannot be moved are displayed on the screen as
the phase reference position (the phase position at "0°" and "360°" are
respectively marked by a solid line and a dotted line). Before you set
manually, the oscilloscope adopts the default phase reference position.
➢ Percent(%): measures ratio at X Cursor. The measurement results
include AX, BX, and △X, and they are all expressed in percentage. This
oscilloscope allows you to set the reference position for the ratio
according to your needs. After adjusting X Cursor to a desired position,
press Set Reference to take the current cursor position as the
reference. The current positions of Cursor A and Cursor B are
respectively defined as "0%" and "100%". Meanwhile, two cursors (in
blue) that cannot be moved are displayed on the screen as the ratio
reference position (the ratio position at "0%" and "100%" are
respectively marked by a solid line and a dotted line). Before you set
manually, the oscilloscope adopts the default ratio reference position.
⚫ When "Y" is selected under Select, you can set the vertical measurement
unit. When the source can be Math1-Math4, this menu is grayed out and
disabled.
Press More → Vert. Unit, and rotate the multifunction knob to select
the vertical measurement unit. Then press down the knob to select it. You
can also press Vert. Unit continuously or enable the touch screen to select it.

Rigol MSO5104 Specifications

General

Type	Tabletop
Product type	-
Bandwidth	100 MHz
Sampling rate	500000 MS/s
Channels quantity	16 channels
Minimum time base setting (per division)	3.5 ns
Display type	LCD
Display diagonal	9 \
AC input voltage	100 - 240 V
AC input frequency	45 - 440 Hz
Power consumption (max)	75 W
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Width	367 mm
