Rigol MSO5104 User Manual

Chapter 8 Power Analysis (Option) RIGOL
MSO5000 User Guide 8-5
the figure below. You can also enable the touch screen to tap the icon at the
right-upper corner of the statistical results window to close it.
⚫ View the Connection Diagram
Press Tips, and then the connection diagram of the ripple analysis is displayed
on the screen. Please connect the cables according to the connection method as
shown in Figure 8-2. Press Tips again or enable the touch screen to tap the icon
at the right-upper corner of the connection diagram window to close it.
Figure 8-2 Connection Diagram of Ripple Analysis

Rigol MSO5104 Specifications

General

Type	Tabletop
Product type	-
Bandwidth	100 MHz
Sampling rate	500000 MS/s
Channels quantity	16 channels
Minimum time base setting (per division)	3.5 ns
Display type	LCD
Display diagonal	9 \
AC input voltage	100 - 240 V
AC input frequency	45 - 440 Hz
Power consumption (max)	75 W
Non-operating altitude	3000 - 15000 m
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Width	367 mm
