The illustration shows, for information purposes only, the machine models, and the legend lists the parts.
Legend:
1. Slide column:
it is used to move the spool carriage vertically.
2. Spool carriage:
it is made of different spool film stretch and pre-stretch systems.
For more details see the table “spool carriage features”.
Vertical movement is activated by the gearmotor (3), activated by an electric motor
powered by the batteries (12).
4. Drive wheel:
it is activated by the electric motor (6), powered by the battery (12), and it is equipped with an electromagnetic
brake.
The electromagnetic brake locks the drive wheel if the battery power supply is interrupted because of a failure
(e.g. broken element) or when the machine is stopped (emergency or cycle Stop).
When the drive wheel is locked, the machine can be moved for short distances by using the temporary-use
spare wheel (
7).
5. Idler wheel:
it is aligned with the drive wheel (4).
7. Temporary-use spare wheel:
it is used to lift the drive wheel (4) from the ground using the handwheel (8) in order to move the machine for
short distances.
10. Rudder:
it is equipped with the directional wheels (9) and it is used to manually move the machine.
11. Feeler:
it is used to follow the pallet perimeter during the wrapping phase.
12. Accumulator batteries:
they power the electric motors and the electric circuit.
13. Emergency bumper:
it is a safety device which stops the machine in case of impact.
For more details, see the paragraph “description of safety devices”.
14. Control panel:
It features electromechanical controls and a touchscreen display to set wrapping parameters.
15. Battery charger:
it is electronic and is used to charge the batteries of the accumulators.
