Robopac ROBOT MASTER - STEERING AND FEELER WHEEL ADJUSTMENTS

ENG
INFORMATION ON ADJUSTMENTS
48
5.5. STEERING WHEEL RETURN SPEED ADJUSTMENT
1. Perform “machine safe stop”.
2. Use the screw (A) to adjust the rudder return speed.
Important
The return speed of the rudder must not be too high to avoid posing a risk to people’s safety.
5.6. ADJUSTING THE HEIGHT OF THE FEELER WHEEL
1. Perform “machine safe stop”.
2. Work on the nut (B) and locknut (B1) to adjust the feeler wheel height.
3. To obtain different heights, remove the nut (B) and fit the wheel (A) from the arm upper side.
