2.10
Comparing the results with
the specified values
15 . 0 5 . 01 09 :33 : 3 0
NO M A G N ET I C C O DE
15 . 0 5 . 01 09 :33 : 3 0
MA G N E T IC C O D E MIS R E A D
15 . 0 5 . 01 09 :34 : 2 5
CH E K 63 8 6 3 9 63 3
Other possible messages:
This means that the magnetic
code has not been read by the
instrument.
Insert the control strip again,
with its magnetic strip facing
downwards and the test area
at the front.
This means that the magnetic
code has not been read fully by
the instrument.
Insert the control strip with its
grey area at the front. If the
same message appears again,
discard the strip and take a
new one.
This indicates that the grey area
has been scanned and its
reflectance measured at the
three measuring wavelengths.
The result is displayed.
Check the three results against
the three ranges printed on the
label to see if the optical
system is working accurately.
If one or more of the three
results obtained lie outside the
specified range, repeat the
measurement with a new con-
trol strip. If this also gives one
or more results lying outside
the specified range, proceed as
described under “Cleaning and
Quality Checking”.
See also R Reflotron Clean +
Check pack insert.
