Rockwell Automation Publication 2198-RM004C-EN-P - March 2022 21
Chapter 2 Replacement Considerations
You can assign the inputs that are listed as — for any of these functions.
• Abort Homing
• Abort Index
•Start Homing
•Start Index
•Fault Reset
• Home Sensor
• Index Select
The digital inputs are optically isolated and sink up to 24V DC. Electrical
details are shown in Table 21
.
Kinetix 5100 Drives
The Kinetix 5100 drives have eight standard inputs and two-high speed inputs,
both with configurable functions. The digital inputs on Kinetix 5100 drives
have the same physical characteristics. Table 22
shows the Kinetix 5100 digital
inputs physical characteristics.
Table 20 - Kinetix 300 Drives Fixed Digital Input Assignments
Digital Input Function
IN_A1 (pin 27) Negative travel limit input
IN_A2 (pin 28) Positive travel limit input
IN_A3 (pin 29) Inhibit/enable input
IN_A4 (pin 30) —
IN_B1 (pin 32) —
IN_B2 (pin 33) —
IN_B3 (pin 34) —
IN_B4 (pin 35) —
IN_C1 (pin 37) —
IN_C2 (pin 38) —
IN_C3 (pin 39) Registration sensor input
IN_C4 (pin 40) —
Table 21 - Kinetix 300 Digital Input Signal Specifications
Attribute Value
Scan time 500 µs
Current max 9 mA, typical
Input impedance 1.2 kΩ, typical
Voltage range 5…24V DC
Table 22 - Kinetix 5100 Digital Input Signal Specifications
Attribute Value
Digital Input response (delay)
Standard inputs: 1.25 ms max
High-speed inputs: 3 µs
Digital Input scan time
Standard inputs: 500us max
High-speed inputs: 1µs
ON state voltage 15V min, 26.4V max
ON state Current 2.0 mA min, 6.0 mA max
OFF state voltage -1.0 V min, 5V max
