Rockwell Automation Publication 2198-RM005A-EN-P - October 2020 15
Replacement Considerations Chapter 1
Continuous output power
@ 110V nom single-phase
@ 230V nom single-phase
@ 230V nom three-phase
0.22 kW
0.46 kW
0.72 kW
0.36 kW
0.76 kW
1.18 kW
0.67 kW
1.41 kW
2.18 kW
0.97 kW
2.02 kW
3.13 kW
Internal shunt on 387.5V
Internal shunt off 377.5V
Internal shunt resistor 100 Ω 100 Ω 60 Ω 60 Ω
Internal shunt power 30 W 30 W 50 W 50 W
Bus undervoltage limit
72V @110V AC input
144V @230V AC input
Bus overvoltage limit 405V
Bus capacitance 330 µF 560 µF 660 µF 1120 µF
Capacitive energy absorption
@ 110V nom AC input
@ 230V nom AC input
21.31 J
5.94 J
36.17 J
10.08 J
42.63 J
11.88 J
72.34 J
20.16 J
Efficiency
91% @110V (single-phase) AC input
95% @230V (single-phase) AC input
97% @230V (three-phase) AC input
Short-circuit current rating
(5)
200,000 A (rms) symmetrical
(1) Drives are limited to one power cycle per minute.
(2) The cooling fan runs as part of the control power startup routine, when the inverter is enabled, and if the inverter temperature exceeds preset threshold.
(3) For current values when motors include a holding brake, refer to Kinetix Servo Drive Specifications Technical Data, publication KNX-TD003
.
(4) Peak RMS current allowed for up to 1.0 seconds.
(5) This rating is only valid if UL specified fuses are used.
Table 11 - Kinetix 5300 (110V and 230V, single-phase and three-phase) Power Specifications (continued)
Attribute 2198-C1004-ERS 2198-C1007-ERS 2198-C1015-ERS 2198-C1020-ERS
Table 12 - Kinetix 5300 (230V, three-phase) Input Power Specifications
Attribute 2198-C2030-ERS 2198-C2055-ERS 2198-C2075-ERS
AC input voltage 170…253V rms, three-phase (230V nom)
AC input frequency 47…63 Hz
Main AC input current (rms)
(1)
15.18 A 31.13 A
36.93 A
Max inrush current (0-pk) 7.4 A 14.8 A
14.8 A
Peak AC input current (rms) 41.26 A 73.06 A
86.25 A
Control power input voltage
(2)
21.6…26.4V DC
24V DC nom
Control power input current
(1)
(3)
(non-brake motors)
0.9 A
DC
1.7 A
DC
1.7 A
DC
Continuous output current (rms) 19.6 A 40.2 A
47.7 A
Continuous output current (0-pk) 27.7 A 56.9 A
67.5 A
Peak output current (rms)
(4)
61.0 A 108.0 A
127.5 A
Peak output current (0-pk) 86.3 A 152.7 A
180.3 A
Line loss ride through 20 ms
Continuous output power 5.02 kW 10.30 kW
12.22 kW
Internal shunt on 387.5V
Internal shunt off 377.5V
Internal shunt resistor 60 Ω 40 Ω
Internal shunt power 50 W 75 W
Bus undervoltage limit 144V
Bus overvoltage limit 405V
Bus capacitance 1680 µF 2460 µF
3280 µF
Capacitive energy absorption 30.25 J 44.29 J
59.05 J
Efficiency 97%
Short-circuit current rating
(5)
200,000 A (rms) symmetrical
(1) Drives are limited to one power cycle per minute.
(2) The cooling fan runs as part of the control power startup routine, when the inverter is enabled, and if the inverter temperature exceeds preset threshold.
(3) For current values when motors include a holding brake, refer to Kinetix Servo Drive Specifications Technical Data, publication KNX-TD003
.
(4) Peak RMS current allowed for up to 1.0 seconds.
(5) This rating is only valid if UL specified fuses are used.
