Rockwell Automation Allen-Bradley PowerFlex 700S Migration Guide

Rockwell Automation Publication 750-RM004A-EN-P - April 2018 127
Enclosure Information Appendix A
Figure 37 - AC and DC Input Frame 13 PowerFlex 700S, IP54 Rittal
F
65
(2.6)
535
(21.1)
H
Ø
2 PLACES
13
E
D
B
122
(4.8)
454
(18.0)
662
(26.1)
A
C
G
Dimensions are in millimeters and (inches).
Voltage Class Amps A B C D E
400/480V AC
(540/650V DC)
1150 1412 (56) 478 (18.8) 678 (26.7) 1 @ 242 (9.5)
1 @ 213 (8.4)
2443.5 (104.5)
max.
1300 1600 (63) 678 (26.7) 678 (26.7) 2 @ 242 (9.5) 2443.5 (104.5)
1450
600/690V AC
(810/932V DC)
920 1412 (56) 478 (18.8) 678 (26.7) 1 @ 242 (9.5)
1 @ 213 (8.4)
2443.5 (104.5)
max.
1030
1180
