128 Rockwell Automation Publication 750-RM004A-EN-P - April 2018
Appendix A Enclosure Information
Figure 38 - AC Input Frame 14 PowerFlex 700S, IP21 Rittal
2232
(88)
603
(24)
620
(24.5)
44
(1.7)
2276
(90)
797 (31.4)
Shipping Split
At This Location
Lifting Points
797 (31.4)797 (31.4)
Lifting Points
2232
(88)
662
(26)
454
(18)
2276
(90)
Shipping Split
At This Location
2400 (94.4)
Lifting Points Lifting Points
797 (31.4) 797 (31.4)797 (31.4)
CLOSE
OPEN
IP54 Rittal
IP21 Rittal
