Enclosure Information Appendix A
Figure 41 - Frame 10 PowerFlex 755TL/TR
3206
(126.6)
1000
(39.4)
800
(31.5)
800
(31.5)
600
(23.6)
709
(27.9)
153
(6.0)
IP21, UL Type 1
2132
(83.9)
IP54, UL Type 12
2291
(90.2)
IP21, UL Type 1
676
(26.6)
IP54, UL Type 12
721
(28.4)
0 (0)
1000 (39.4)
3135 (123.4)
2400 (94.5) 2335 (91.9) 1800 (70.9) 1735 (68.3) 1000 (39.4)
935 (36.8)
2668 (105.0) 2768 (109.0) 2872 (113.1) 2964 (116.7) 3072 (120.9)
2468 (97.2)
2564 (100.9)
450
(17.7)
45
(1.8)
200
(7.9)
200
(7.9)
230
(9.1)
186
(7.3)
1481
(58.3)
200
(7.9)
726
(28.6)
473
(18.6)
45
(1.8)
36
(1.4)
150
(5.9)
105
(4.1)
535
(21.1)
Power BayInput Bay Power Bay
Control Cables - Top Entry
Signal Cables - Bottom Entry
Input Power Cables - Bottom Entry Motor Cables - Bottom Exit
(Plate is marked with recommended
gland or conduit hole pattern.)
Power Bay
Mounting Holes
