7-4 Troubleshooting
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
43
44
45
46
47
48
HW Addr 1
HW Addr 2
HW Addr 3
HW Addr 4
HW Addr 5
HW Addr 6
Decimal value of each byte in the adapter’s Ethernet hardware address.
49
50
51
52
IP Addr Act 1
IP Addr Act 2
IP Addr Act 3
IP Addr Act 4
Value of each byte in the adapter’s current IP address. A value of “0” appears if the adapter does
not currently have an IP address.
53
54
55
56
Subnet Act 1
Subnet Act 2
Subnet Act 3
Subnet Act 4
Value of each byte in the adapter’s current subnet mask. A value of “0” appears if the adapter does
not currently have a subnet mask.
57
58
59
60
Gateway Act 1
Gateway Act 2
Gateway Act 3
Gateway Act 4
Value of each byte in the adapter’s current gateway address. A value of “0” appears if the adapter
does not currently have a gateway address.
61 Net Rx Overruns Number of receive buffer overruns reported by the Ethernet hardware.
62 Net Rx Packets Number of Ethernet packets that the adapter has received.
63 Net Rx Errors Number of receive errors reported by the Ethernet hardware.
64 Net Tx Packets Number of Ethernet packets that the adapter has sent.
65 Net Tx Errors Number of transmit errors reported by the Ethernet hardware.
66 Last TCP Reset Last reason that the adapter reset or rejected a TCP/IP connection.
67 Missed IO Pkts Number of incoming I/O connection packets that the adapter did not receive.
68 Net Addr Sw The present value of the adapter node address switches.
Table 7.A Adapter Diagnostic Items (Continued)
No. Name Description
255 : 255 : 255 : 255 : 255 : 255
[HW Addr 1]
[HW Addr 2]
[HW Addr 3]
[HW Addr 4]
HW Addr 5]
[HW Addr 6]
255 . 255 . 255 . 255
[IP Addr Act 1]
[IP Addr Act 2]
[IP Addr Act 3]
[IP Addr Act 4]
255 . 255 . 255 . 255
[Subnet Act 1]
[Subnet Act 2]
[Subnet Act 3]
[Subnet Act 4]
255 . 255 . 255 . 255
[Gateway Act 1]
[Gateway Act 2]
[Gateway Act 3]
[Gateway Act 4]
