EtherNet/IP Objects C-25
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
DPI Time Object
Class Code
Services
Instances
The number of instances depends on the number of timers in the device.
Instance 1 is always reserved for a real time clock although a device
may not support it. The total number of timers can be read in Instance 0,
Attribute 2.
Class Attributes
Hexadecimal Decimal
0x9B 155
Service Code
Implemented for:
Service NameClass Instance
0x0E Yes Yes Get_Attribute_Single
0x10 Yes Yes Set_Attribute_Single
Instances (Hex.) (Dec.) Device Example Description
0x0000 – 0x3FFF 0 – 16383 Host Drive 0 Class Attributes (Drive)
0x4000 – 0x43FF 16384 – 17407 Adapter 1 Real Time Clock (Predefined)
(not always supported)
0x4400 – 0x47FF 17408 – 18431 Port 1 2 Timer 1
0x4800 – 0x4BFF 18432 – 19455 Port 2 3 Timer 2
0x4C00 – 0x4FFF 19456 – 20479 Port 3
…
…
0x5000 – 0x53FF 20480 – 21503 Port 4
0x5400 – 0x57FF 21504 – 22527 Port 5
0x5800 – 0x5BFF 22528 – 23551 Port 6
0x5C00 – 0x5FFF 23552 – 24575 Port 7
0x6000 – 0x63FF 24576 – 25599 Port 8
0x6400 – 0x67FF 25600 – 26623 Port 9
0x6800 – 0x6BFF 26624 – 27647 Port 10
0x6C00 – 0x6FFF 27648 – 28671 Port 11
0x7000 – 0x73FF 28672 – 29695 Port 12
0x7400 – 0x77FF 29696 – 30719 Port 13
0x7800 – 0x7BFF 30720 – 31743 Port 14
Attribute ID Access Rule Name Data Type Description
1 Get Class Revision UINT Revision of object
2 Get Number of Instances UINT Number of timers in the object, excluding the
real time clock that is predefined.
3 Get First Device Specific Timer UINT Instance of the first timer that is not predefined.
4 Set Time Command Write USINT 0 = No Operation
1 = Clear all timers (Does not clear the real time
clock or read only timers)
5 Get Number of Supported Time Zones UINT Number of time zones described in the Time
Zone List attribute.
6 Get Time Zone List STRUCT Identifies a time zone.
