C-6 EtherNet/IP Objects
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
PCCC Object
Class Code
Services
Instances
Supports Instance 1.
Class Attributes
Not supported.
Instance Attributes
Not supported.
Message Structure for Execute_PCCC
Hexadecimal Decimal
0x67 103
Service Code
Implemented for:
Service NameClass Instance
0x4B No Yes Execute_PCCC
0x4C No Yes Execute_DH+
Request Response
Name Data Type Description Name Data Type Description
Length USINT Length of requestor ID Length USINT Length of requestor ID
Vendor UINT Vendor number of requestor Vendor UINT Vendor number of requestor
Serial
Number
UDINT ASA serial number of
requestor
Serial
Number
UDINT ASA serial number of
requestor
Other Product
Specific
Identifier of user, task, etc.
on the requestor
Other Product
Specific
Identifier of user, task, etc.
on the requestor
CMD USINT Command byte CMD USINT Command byte
STS USINT 0 STS USINT Status byte
TNSW UINT Transport word TNSW UINT Transport word. Same value
as the request.
FNC USINT Function code. Not used for
all CMDs.
EXT_STS USINT Extended status. Not used
for all CMDs.
PCCC_
params
ARRAY of
USINT
CMD/FNC specific
parameters
PCCC_
results
ARRAY of
USINT
CMD/FNC specific result
data
