DPI Device Information
Pages
DPI device information pages consist of these five pages:
• Module information page
• Diagnostic items page
• Fault queue page
• Alarm queue page
• Event queue page
Figure 8.6
shows an example module information page for the Port 00
device (host drive). Figure 8.7
, Figure 8.8, and Figure 8.9 respectively
show example diagnostic items, fault queue, and alarm queue pages for
this device. Figure 8.10
shows an example event queue page for the Port
13 device (the embedded EtherNet/IP adapter).
Figure 8.6 Example of Port 00 (PowerFlex 755 Drive) Module Information Page
Information Description
Product Text Text identifying the device
Vendor ID 1 = Allen-Bradley
Device Type 0x008F (143 decimal)
Product Code Code for the product name and its rating
Revision Firmware revision used by the device
Serial Number Serial number of the device
Status Operating status of the device (for example, faulted)
