C-4 EtherNet/IP Objects
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
Register Object
Class Code
Services
Instances
Class Attributes
Hexadecimal Decimal
0x07 7
Service Code
Implemented for:
Service NameClass Instance
0x0E Yes Yes Get_Attribute_Single
0x10 Yes Yes Set_Attribute_Single
Instance Description
1 All I/O data being read from the embedded adapter (read-only)
2 All I/O data written to the embedded adapter (read/write)
3 Logic Status and Feedback data (read-only)
4 Logic Command and Reference data (read/write)
5 DL To Net 01 (input data from embedded adapter to scanner) (read only)
6 DL From Net 01 (output data from scanner to embedded adapter) (read/write)
… …
35 DL To Net 16 (output data from scanner to embedded adapter) (read/write)
36 DL From Net 16 (input data from embedded adapter to scanner) (read only)
37 Logic Status and Feedback data (read-only)
38 Masked Logic Command
(1)
(read/write)
(1)
The mask command DWORD is set to the value of the first DWORD of the data where there are ones in
the second DWORD of the data. Only the bits of the Logic Command that have the corresponding mask
bit set are applied.
39 Logic Status data (read-only)
40 Logic Command data (read/write)
41 Feedback data (read-only)
42 Reference data (read/write)
Attribute ID Access Rule Description
1 Read Revision
2 Read Maximum Instance
3 Read Number of Instances
100 Read/Write Timeout
