EtherNet/IP Objects C-9
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
N-File Description
N150 – N199 These N-files let you read and write parameter values in the PowerFlex 755 drive
as 32-bit double words. You can interpret the data in various ways (for example,
32-bit real, 32-bit integer) To read a parameter, you need to send a message with
two elements. For example, to read parameter 1, read two elements beginning at
N150:2. As another example, to read parameters 2 - 6, read ten elements
beginning at N150:4.
N150:0 – 1
N150:2 – 249
N151:0 – 249
N152:0 – 249
N153:0 – 249
Number of parameters in the drive
Drive parameters 1 – 124
Drive parameters 125 – 249
Drive parameters 250 – 374
Drive parameters 375 – 499
...
...
N199:0 – 249 Drive parameters 6125 – 6249
N201 – N212 These N-files let you read and write parameter values in DPI Peripherals (for
example, a HIM or adapter) as 32-bit double words. You can interpret the data in
various ways (for example, 32-bit real, 32-bit integer) To read a parameter, you
need to send a message with two elements. For example, to read parameter 1 in
the peripheral connected to DPI port 1, read two elements beginning at N201:2.
As another example, to read parameters 2 – 6 in the peripheral connected to DPI
port 5 (the adapter), read ten elements beginning at N209:4.
N201:0 – 1
N201:2 – 249
N202:0 – 249
N203:0 – 1
N203:2 – 249
N204:0 – 249
N205:0 – 1
N205:2 – 249
N206:0 – 249
N207:0 – 1
N207:2 – 249
N208:0 – 249
N209:0 – 1
N209:2 – 249
N210:0 – 249
N211:0 – 1
N211:2 – 249
N212:0 – 249
N213:0 – 1
N213:2 – 249
N214:0 – 249
N215:0 – 1
N215:2 – 249
N216:0 – 249
N217:0 – 1
N217:2 – 249
N218:0 – 249
N219:0 – 1
N219:2 – 249
N220:0 – 249
N221:0 – 1
N221:2 – 249
N222:0 – 249
N223:0 – 1
N223:2 – 249
N224:0 – 249
N225:0 – 1
N225:2 – 249
N226:0 – 249
N227:0 – 1
N227:2 – 249
N228:0 – 249
Number of parameters in the DPI peripheral at DPI port 1
Parameters 1 – 124 in the DPI peripheral at DPI port 1
Parameters 125 – 249 in the DPI peripheral at DPI port 1
Number of parameters in the DPI peripheral at DPI port 2
Parameters 1 – 124 in the DPI peripheral at DPI port 2
Parameters 125 – 249 in the DPI peripheral at DPI port 2
Number of parameters in the DPI peripheral at DPI port 3
Parameters 1 – 124 in the DPI peripheral at DPI port 3
Parameters 125 – 249 in the DPI peripheral at DPI port 3
Number of parameters in the DPI peripheral at DPI port 4
Parameters 1 – 124 in the DPI peripheral at DPI port 4
Parameters 125 – 249 in the DPI peripheral at DPI port 4
Number of parameters in the DPI peripheral at DPI port 5
Parameters 1 – 124 in the DPI peripheral at DPI port 5
Parameters 125 – 249 in the DPI peripheral at DPI port 5
Number of parameters in the DPI peripheral at DPI port 6
Parameters 1 – 124 in the DPI peripheral at DPI port 6
Parameters 125 – 249 in the DPI peripheral at DPI port 6
Number of parameters in the DPI peripheral at DPI port 7
Parameters 1 – 124 in the DPI peripheral at DPI port 7
Parameters 125 – 249 in the DPI peripheral at DPI port 7
Number of parameters in the DPI peripheral at DPI port 8
Parameters 1 – 124 in the DPI peripheral at DPI port 8
Parameters 125 – 249 in the DPI peripheral at DPI port 8
Number of parameters in the DPI peripheral at DPI port 9
Parameters 1 – 124 in the DPI peripheral at DPI port 9
Parameters 125 – 249 in the DPI peripheral at DPI port 9
Number of parameters in the DPI peripheral at DPI port 10
Parameters 1 – 124 in the DPI peripheral at DPI port 10
Parameters 125 – 249 in the DPI peripheral at DPI port 10
Number of parameters in the DPI peripheral at DPI port 11
Parameters 1 – 124 in the DPI peripheral at DPI port 11
Parameters 125 – 249 in the DPI peripheral at DPI port 11
Number of parameters in the DPI peripheral at DPI port 12
Parameters 1 – 124 in the DPI peripheral at DPI port 12
Parameters 125 – 249 in the DPI peripheral at DPI port 12
Number of parameters in the DPI peripheral at DPI port 13
Parameters 1 – 124 in the DPI peripheral at DPI port 13
Parameters 125 – 249 in the DPI peripheral at DPI port 13
Number of parameters in the DPI peripheral at DPI port 14
Parameters 1 – 124 in the DPI peripheral at DPI port 14
Parameters 125 – 249 in the DPI peripheral at DPI port 14
