Rockwell Automation PowerFlex 755 Drive

C-20 EtherNet/IP Objects
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
Instance Attributes
5 Get Fault Data List STRUCT of:
USINT
USINT
UINT[n]
Reserved
6 Get Number of Recorded Faults UINT Number of faults/events in the queue. A “0”
indicates the fault queue is empty.
7 Get Fault Parameter Reference UINT Reserved
Attribute ID Access Rule Name Data Type Description
Attribute ID Access Rule Name Data Type Description
0 Get Full/All Information STRUCT of
UINT
STRUCT of:
USINT
USINT
STRING[16]
STRUCT of:
LWORD
BOOL[16]
UINT
CONTAINER[n]
Fault code
Fault source
DPI port
DPI Device Object
Fault text
Fault time stamp
Timer value (0 = timer not supported)
BOOL[0]: (0 = invalid data, 1 = valid data)
BOOL[1]: (0 = elapsed time, 1 = real time)
BOOL[2 - 15]: Not used
Reserved
Reserved
1 Get Basic Information STRUCT of:
UINT
STRUCT of:
USINT
USINT
STRUCT of:
LWORD
BOOL[16]
Fault code
Fault source
DPI port
DPI Device Object
Fault time stamp
Timer value (0 = timer not supported)
BOOL[0]: (0 = invalid data, 1 = valid data)
BOOL[1]: (0 = elapsed time, 1 = real time)
BOOL[2 - 15]: Not used
2 Get International Fault Text STRINGN Text describing the fault with support for Unicode.
