Configuring the I/O 4-7
PowerFlex® 755 Drive Embedded EtherNet/IP Adapter User Manual
Publication 750COM-UM001A-EN-P
Three buttons at the bottom left of the Module Definition screen are
provided for your convenience to perform specific functions:
• Create Database: Clicking this button enables you to create a
database from an online network device. Thereafter, the database
appears in the list for selection on the Module Definition screen.
• Web Update: Clicking this button opens the Allen-Bradley Web
Updates web site for downloading product-specific firmware
update files.
• Match Drive: This button is useful when the drive being added
to the network matches the drive profile (revision, rating,
Datalinks, configuration settings, etc.) of an existing online
network drive. Clicking this button conveniently creates a
duplicate drive profile from the online drive, and automatically
loads this identical information into the Module Definition
screen. This eliminates the need to manually enter the
information each time a new drive with a matching profile is
added to the network.
On the Module Definition screen, notice that the Drive Status,
Feedback, Logic Command, and Reference are always used.
However, when using Datalinks you must still assign adapter
Parameters 01-16 - [DL From Net 01-16] and Parameters 17-32
Electronic
Keying
Compatible Module. The “Compatible Module” setting for Electronic
Keying ensures the physical module is consistent with the software
configuration before the controller and bridge make a connection.
Therefore, ensure that you have set the correct revision in this screen.
Refer to the online Help for additional information on this and other
Electronic Keying settings. If keying is not required, select “Disable
Keying.”
Drive Rating The voltage and current rating of the drive. If the drive rating is not listed,
the drive database is not installed on your computer. To get the correct
database, click either the Create Database…, Web Update…, or Match
Drive button on the bottom left of this screen. See the information
following this table for descriptions of each button.
Rating Options Selects the drive power output required for the application.
Special Types Reserved for future use.
Connection Parameters via Datalinks. When selecting “Parameters via Datalinks”
(default), the controller tags for the Datalinks use the drive parameter
names to which they are assigned. When selecting “Datalinks,” the
controller tags for the Datalinks have non-descriptive UserDefinedData[n]
names like those used in RSLogix 5000 v15.
Data Format Parameters. When the Connection field is set to “Parameters via
Datalinks,” “Parameters” is automatically selected. When the Connection
field is set to “Datalinks,” you must select the number of Datalinks
required for your application in the “Data Format” field.
Input Data Assigns selected drive or connected peripheral parameters to be READ
by the controller using DL To Net Datalinks. See Steps 5A through 5E
below for details.
Output Data Assigns selected drive or connected peripheral parameters to be
WRITTEN to the controller using DL From Net Datalinks. See Steps 5A
through 5E below for details.
Use Network
Reference Box
Conveniently selects the speed reference for the drive to come from the
network. This box is checked by default.
Box Setting
