46
Example 3: The signal decoder is congured to address 5, and the standard signal conguration (Signal-ID=71 “Universal”) is set.
Now send the switching command 2G in order to display “Proceed with 40 km/h” on the rst signal. The second turnout number which
is assigned to the signal is 6.
This procedure can also be used in the Z21 App.
Example 4: The signal decoder is congured to address 1, and the standard signal conguration (Signal-ID=71 “Universal”) is set.
Congure the signal in the Z21 App as shown in order to switch the appropriate signal aspects with the commands 1R, 1G, 2R or 2G.
