Appendix B - Signal con gurations
The following signal congurations are included on delivery condition FW V1.10 in the Z21 signal DECODER, and can be selected via
the Z21 per LINK or CV #41 to #44. See also Connecting the Z21 signal DECODER, Operation on DCC control centres, Conguration
and rmware update via zLink.
INFORMATION: You can always nd all the latest details on the individual signal congurations online under: https://www.
z21.eu/en/products/z21-signal-decoder/signaltypen.
In addition to country-specic signals, you can also nd internationally-applicable congurations in the following table, for example
the highly exible signal congurations “Universal” or “Railway crossing”. There are also congurations which can be used for general
lighting purposes.
Signal-ID Name Image
decimal hex
64 0x40 4 single LEDs
4 single lamps, individually switchable.
65 0x41 4 fading LEDs
4 single lamps, individually switchable with light bulb
simulation (gentle fade-up and fade-down).
67 0x43 4 running lights
4 warning lamps for construction sites (guiding light
system)
Running light
Illuminated advertising
Warning light for emergency vehicles (blue light)
71 0x47 Universal
Highly exible conguration for light signals of simpler
construction from different countries.
INFORMATION: This is the factory setting.
72 0x48 Universal #2
Like Universal, but with a red ashing light for “Subs-
titution” (for SBB, SNCF).
73 0x49 Railway crossing
Internationally-applicable alternate ash for railway
crossings, optionally with white operational readiness
display and yellow trackside signal for the traction unit
driver.
77 0x4D 10777
Similar to ROCO 10777.
