Signal-ID Name Image
decimal hex
160 0xA0 ÖBB main signal Ep 4-6
Main signal of modern construction, with substitution
signal, movement forbidden cancelled, shunting for-
bidden cancelled and departure signal.
161 0xA1 ÖBB distant signal
Four-aspect distant signal, with dark switching.
162 0xA2 ÖBB semaphore main signal
Two or three-aspect semaphore main signal with light-
ing and double-assigned outputs for the coil drives.
Observe the information on semaphore signals under
https://www.z21.eu/en/products/z21-signal-decoder/
signaltypen
163 0xA3 ÖBB semaphore distant signal
Two-aspect semaphore distant signal with lighting.
Observe the information on semaphore signals under
https://www.z21.eu/en/products/z21-signal-decoder/
signaltypen
164 0xA4 ÖBB protection signal Ep 4-6
Protection signal of modern construction with substi-
tution signal and departure signal (optional).
165 0xA5 ÖBB protection signal Ep 3-4
Protection signal, older construction with additional
outputs for substitution signal or 29b.
166 0xA6 ÖBB shunting signal
Shunting signal of more modern or older construction
with additional output for the proceed signal.
167 0xA7 ÖBB signal emulator
Signal emulator with additional outputs for substitu-
tion signal or 29b, as well as departure signal.
168 0xA8 ÖBB brake test, departure
Brake test signal and departure signal, can be used
together or separately.
