EN
49
4 Technical characteristics of product
H70/200AC
MAINS POWER VOLTAGE 230 V
± 10% 50 Hz
MAXIMUM MAINS POWER ABSORP-
TION
1400 W
FUSES
F1 = F6,3A 250 V (5x20) motor power circuit protection
F2 = F630mA 250 V (5x20) accessories power supply protection
CONNECTABLE MOTORS 2
MOTOR POWER SUPPLY 230 V
MOTOR TYPE single-phase asynchronous
MOTOR CONTROL TYPE triac phase control
MAXIMUM MOTOR POWER 600 W
MAXIMUM POWER, FLASHING LIGHT 40 W 230 V
- 25 W 24 V / (potential free contact)
MAXIMUM POWER COURTESY LIGHT 100 W 230 V
- 25 W 24 V / (potential free contact)
ELECTRIC LOCK POWER 25 W (potential free contact) max. 230 V
GATE OPEN LIGHT POWER 3 W (24 V )
MAXIMUM ACCESSORY CURRENT
ABSORPTION
9 W
OPERATING TEMPERATURE
-20°C +55°C
DEGREE OF PROTECTION IP44
SOUND PRESSURE DURING USE <70 dB(A)
PRODUCT DIMENSION dimensions in mm 137x156x43 WeightOK
