Roger Technology H70/200AC Instruction And Warnings For The Installer
4
of 1
of 1 rating
40 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
4
FW
V1.5
1
3
Table of Contents
Default Chapter
2
Parts View
2
Diagrams
3
Photocells
5
Photocells Test
6
Flashing Light
7
With Optical Encoder
8
Safety Information
9
Product Description
11
Symbols
11
Technical Characteristics
12
Description of Connections
13
Typical Installation
13
Electrical Connections
14
Commands and Accessories
15
Switching on or Commissioning
17
Function Buttons and Display
17
Parameter Display Mode
17
Display Function Modes
17
Command and Safety Device Status Display Mode
18
Command Status
18
Safety Device Status
18
Standby Mode
19
Test Mode
19
Travel Acquisition
20
Acquisition Procedure with the Encoder Enabled
21
Acquisition Procedure WITHOUT Encoder
22
Table of Contents
25
Index of Parameters
25
Factory
26
Parameter Menu
27
Motor Type Selection
27
Automatic Close after Pause Time (from Gate Completely Open)
27
Automatic Gate Closing after Mains Power Outage (Black-Out)
27
Selecting Step Mode Control Function (PP)
27
Condominium Function for Partial Open Command (PED)
27
Enabling Operator Present Function
28
Gate Open Indicator / Photocell Test Function
28
Set MOTOR 1 Deceleration Space (%)
28
Set MOTOR 2 Deceleration Space (%)
28
Adjusting LEAF 1 Position Control
28
Adjusting LEAF 2 Position Control
28
Partial Opening Adjustment (%)
28
Setting Additional Time after Direction Inversion, with no Encoder
28
Setting Automatic Closing Time
28
MOTOR 1 Operating Time Increase
29
MOTOR 2 Operating Time Increase
29
Enable Double Manoeuvre Time
29
Adjusting Opening Delay of MOTOR 2
29
Adjusting Closing Delay of MOTOR 1
29
Setting Reverse Time after Activation of Sensing Edge or Obstacle Detection (Crush Prevention)
29
Setting Electric Lock Activation Lead Time
29
Setting Electric Lock Activation Time
29
Set Motor Torque During Manoeuvre
29
Set Motor Torque During Deceleration
29
Set Initial Acceleration When Opening/Closing (Soft-Start)
30
Set Torque after Activation of Sensing Edge or Obstacle Detection System
30
Set Initial Maximum Torque Boost Time
30
Set Open/Closed Stop Approach Distance
30
Enable Lock Release Reverse Impulse
30
Set Deceleration During Opening/Closure
30
Set Obstacle Detection Sensitivity During Manoeuvres
30
Set Obstacle Detection Sensitivity During Deceleration
30
Number of Automatic Closure Attempts after Activation of Sensing Edge or Obstacle Detection (Crush Protection)
31
Setting Photocell Mode During Gate Opening (FT1)
31
Setting Photocell Mode During Gate Closing (FT1)
31
Photocell (FT1) Mode with Gate Closed
31
Setting Photocell Mode During Gate Opening (FT2)
31
Setting Photocell Mode During Gate Closing (FT2)
31
Photocell (FT2) Mode with Gate Closed
32
Enable Close Command 6 S after Activation of Photocell (FT1-FT2)
32
Enable Braking at Open and Closed Mechanical Stop/Limit Switch
32
Enable Braking after Activation of Photocells
32
Enable Braking after STOP Command
32
Enable Braking after Open > Close / Close > Open Inversion
32
Set Braking Time
32
Set Braking Force
32
Select Number of Motors Installed
32
Enable Limit Switches
32
Selecting Courtesy Light Mode
33
Restoring Factory Default Values
34
HW Version
34
Year of Manufacture
34
Week of Manufacture
34
Serial Number
34
FW Version
34
View Manoeuvre Counter
34
View Manoeuvre Hour Counter
34
View Control Unit Days on Counter
34
Password
35
Example Installation with Two Opposing Automation System
36
Safety Input and Command Status (TEST Mode)
37
Alarms and Faults
38
Mechanical Release
38
Position Recovery Mode
38
Initial Testing
39
Start-Up
39
Maintenance
39
Disposal
39
Param
26
Default
27
