Set initial acceleration when opening/closing (soft-start)
Disabled.
Enabled. The gate accelerates slowly and progressively at the start of the manoeuvre.
Enabled. The gate accelerates even more slowly and progressively at the start of the manoeuvre.
2&ZEPYIWEZEMPEFPISRP]MJIRGSHIVMWIREFPIH different from ). Setting a value of is not
recommended for heavy gates.
Set motor torque after activation of sensing edge or encoder.
Disabled. Torque applied is the value set for parameter .
1 = minimum motor torque ... 8 = maximum motor torque.
Enable maximum torque boost at start of manoeuvre
If this parameter is enabled, each time the motor starts the maximum boost torque is applied for a
settable period of time to allow the gate to start moving.
From 0 to 20 s.
Set open/closed stop approach distance
Disabled.
= 0.5 m long gate leaf; = 1 m long gate leaf; = 1.5 m long gate leaf; = 2 m long gate leaf;
!KEXIPIEJƶQMRPIRKXL
-JXLMWJYRGXMSRMWIREFPIHXLIXSVUYIETTPMIHMWVIHYGIHHYVMRKXLIƼREPTEVXSJXLIKEXIXVEZIPXSVIHYGI
gate vibration when it reaches the stop.
3RMRWXEPPEXMSRW[MXLERIPIGXVMGPSGOXLIXSVUYIETTPMIHMWMRGVIEWIHHYVMRKXLIƼREPTEVXSJXLIGPSWMRK
travel to ensure that the lock latches correctly. On installations with no electric lock, the torque applied is
VIHYGIHHYVMRKXLIƼREPTEVXSJXLIKEXIXVEZIPXSVIHYGIKEXIZMFVEXMSR
2&TEVEQIXIVZMWMFPISRP]MJIRGSHIVMWIREFPIH .
Enable electric lock release reverse impulse
Disabled.
Enabled. At the start of each opening manoeuvre, the control unit applies a brief closing force (settable
from 1 to 4 s) to release the electric lock.
Enabling the electric lock release reverse impulse function automatically enables parameters
(electric lock lead time = 1 s) and (electric lock activation time = 3 s).
Set deceleration during opening/closure
Disabled.
Medium deceleration.
N.B.QE\MQYQWIXXEFPIZEPYIJSVTSPIQSXSVW666,6
R41/833)..
Maximum deceleration. IMPORTANT9WIONLY in oustanding possibilities, for example gates very
light. DO NOT USE 6 pole motors (R20/302, R20/502, R21/368, H23/282, R41/832, R41/833).
Set obstacle detection sensitivity during manoeuvres
The gate reverses immediately when an obstacle is detected during an opening or closing mano-
euvre.
NOTE8LIQE\MQYQZEPYIMWPMQMXIHXS for 6-pole slow motors ($ ).
Set obstacle detection sensitivity during deceleration
The gate reverses immediately when an obstacle is detected during opening or closing deceleration.
NOTE8LIQE\MQYQZEPYIMWPMQMXIHXS for 6-pole slow motors ($ ).
From 1% to 99%. = minimum sensitivity ... = maximum sensitivity.
