Page #268 background image
268
Parameter List
Startup Group (P.234)
System Information Group (P.234)
D Beam (Solo Synth) Group (P.123)
Mastering Effect Group (P.217)
Input Setting Group (P.141)
Parameter
Value
Load Preset Samples at Startup
OFF, ON
Load User Samples at Startup OFF, ON
Load Demo Song at Startup OFF, ON
Rec Track Sellect Manual, Auto
Power Up Mode PATCH, PERFORMANCE
Parameter
Features
Displays the main features of the Fantom-X.
Memory Info Memory Information
SRX Info SRX Information
Version Info Version Information
Parameter
Value
OSC1/2 Waveform
SAW, SQR
OSC1/2 Pulse Width 0–127
OSC1/2 Coarse Tune -48– +48
OSC1/2 Fine Tune -50– +50
OSC2 Level 0–127
OSC Sync Switch OFF, ON
Filter Type OFF, LPF, BPF, HPF, PKG
Cutoff 0–127
Resonance 0–127
Level 0–127
Chorus Send Level 0–127
Reverb Send Level 0–127
LFO Rate 0–127
LFO Osc 1 Pitch Depth -63– +63
LFO Osc 2 Pitch Depth -63– +63
LFO Osc 1 Pulse Width Depth -63– +63
LFO Osc 2 Pulse Width Depth -63– +63
Range Solo Synth Range 2 OCTAVE, 4 OCTAVE, 8 OCTAVE
Parameter
Value
HIGH/MID/LOW ATTACK
0–100 ms
HIGH/MID/LOW RELEASE 50–5000 ms
HIGH/MID/LOW THRESHOLD -36–0 dB
HIGH/MID/LOW RATIO 1.00:1–INF:1 (INF: Infinity)
HIGH/MID/LOW LEVEL 0–24 dB
Split Frequency High 2000–8000 Hz
Split Frequency Low 200–800 Hz
Parameter Value
Input Select DIGITAL IN, LINE IN L/R, LINE IN L, MICROPHONE
Mix-In ON, OFF
Mix In Output Assign DRY, MFX
Mix In Output Level 0–127
Mix In Chorus Send Level 0–127
Mix In Reverb Send Level 0–127
Input Effect Switch ON, OFF
Input Effect Type EQ, ENHANCER, COMP, LIMITER, NOISE SUP, C
CANCELER
Fantom-X678_r_e.book 268 ページ 2005年5月12日 木曜日 午後4時40分
