Roland Soljet EJ-640 - Page 66

Maintenance That Should Be Performed Once a Month or More
3
Maintenance
64
3. Clean the area around the print heads with the cleaning stick.

Open the left cover.

Remove the bolt (), and then remove the cut rail ().
Press
.

Close the left cover.

Open the left cover.

Open the right cover.
Preparations are complete when this screen appears.
OPEN COVER L
Click!
REMOVE CUT
RAIL
CLOSE COVER L
Click!
OPEN COVER L
OPEN COVER R
FINISHED?
