Roland Soljet EJ-640 - Replacing the Felt Wipers

Replacing Consumable Parts
3
Maintenance
74
Replacing the Felt Wipers
The felt wipers are parts used for cleaning the print heads. When the screen displays a message like the one
shown below, it is time to replace the items. There are two felt wipers. Replace both felt wipers with new ones.
For information about purchasing felt wipers, contact your authorized Roland DG Corp. dealer.
CAUTION
Be sure to perform operations as specied by the instructions, and never
touch any area not specied in the instructions.
Sudden movement of the machine may cause injury.
1. Enter the felt wiper replacement menu.

When the message shown in the gure appears, press
.

Remove any media.

Press .

Press several times to display the screen shown
on the left.
Press
.

Press several times to display the screen shown
on the left.
Press
.

Press several times to display the screen shown
on the left.
Press
.
The print-head carriage moves to a location where felt wiper replace-
ment is possible, and then the screen shown on the left appears.
TIME FOR
FELT REPLACE
Required items
TIME FOR
FELT REPLACE
MENU
SUB MENU
SUB MENU
MAINTENANCE
MAINTENANCE
REPLACE FELT
OPEN COVER R
Felt wipers Tweezers
