Fully Utilizing the Correction Function
Correcting for Misalignment in Bidirectional Printing
Procedure
Press .
Press several times to display the screen shown
on the left.
Press
.
Press .
A test pattern is printed.
When printing ends, press , then .
Press or to select the correction value.
Press
to conrm your entry.
Press , then to go back to the original screen.
Description
This machine prints by the bidirectional mode (in which the print heads perform printing during both their
outbound pass and return pass). This printing method is called "Bidirectional Printing."
This method oers the advantage of being able to shorten output times, but subtle misalignment occurs during
the outbound and return passes. The procedure to correct this and eliminate misalignment is "Bidirectional
Correction." This misalignment varies according to the print head height and the thickness of the media, so
we recommend performing correction to match the media you are using.
Correcting for Misalignment in Bidirectional Printing More Precisely
When further correction is required, such as when adjustment made using [SIMPLE SETTING] does not enhance
printing, use [DETAIL SETTING] to make corrections.
For instructions on how to perform the work, refer to P. 30, "Performing the Initial Adjustment (Correcting
for Misalignment in Bidirectional Printing More Precisely)".
To decide a correction value
Choose the value that produces the least misalignment of the 2 lines. When you cannot choose be-
tween two numbers, select a value that is halfway between them.
Correction-value scale
The least misalignment
= Current
correction value
