Maintenance That Should Be Performed Once a Month or More
3
Maintenance
66
4.
Reattach the left and right covers, and then end the manual cleaning mode.
Close the left cover.
Close the right cover.
Open the left cover.
Attach the cut rail (), and then secure it in place with
the bolt ().
Press
.
Close the left cover.
The screen shown in the gure appears, and then cleaning starts.
The remaining process time (estimated) is displayed on the screen.
("01:45" = "1 minute and 45 seconds")
When cleaning nishes, the screen shown in the gure appears again.
Press , then to go back to the original screen.
5.
Perform a printing test to verify the results of the procedure.
Perform a printing test to check the results.
Perform cleaning using the machine’s cleaning feature several times when necessary.
P. 40, "Printing Tests and Normal Cleaning"
CLOSE COVER L
CLOSE COVER R
OPEN COVER L
REPLACE CUT
RAIL
CLOSE COVER L
CLEANING..
>>>>>> 01:45
MAINTENANCE
CLEANING
