Replacing Consumable Parts
3
Maintenance
78
2.
Replace the separating knife
Remove the separating knife.
Loosen the screw until it slips out.
Grasp the screw portion, and slowly pull
it out in the direction of the arrow. When
doing this, do not pull it back toward you.
Install a new knife.
The knife is secured in place by the magnet.
Slowly insert it into the groove.
Tighten the screw.
Take care to ensure that the knife does not slip out
of position at this time.
Magnet
Positioning
groove
To Next Page
