RootWave Pro User Guide
Components
This section describes the following main components of RootWave
Pro:
• Power Module TRA-001-3 or TRA-002-3
• Treatment Lance APL-001-3
• Electrode Module ETD-001-3 (also applies to alternative Electrode
Module formats ETD-002-3, ETD-003-3,ETD-004-3 and ETD-005-3)
• Treatment Return GRW-001-3
• Safety Earth GRW-002-3
Power Module TRA-001-3 or TRA-002-3
The Power Module creates high-voltage electricity, and provides
some of the controls for RootWave Pro. Additional controls are
provided on the Treatment Lance.
Figure 2 Power Module interfaces
1
2
3
4
5
12
11
10
6
7
8
9
