Treatment Lance

Voltage levels

(nominal)

Low: 3,000 VAC +/- (5+supply stability)%

Medium: 4,000 VAC +/- (5+supply stability)%

High: 5,000 VAC +/- (5+supply stability)%

Current rating

0- 1.7 A RMS +5% (input stability and load

reactance dependent)

Frequency

50 Hz +/- 2% (input stability dependent)

Short circuit

Secondary side short circuit stable. Current

limiting a function of Primary side supply

capabilities and internal primary side 32 A fuse.

See "Note 2".

Charge storage

(Primary side)

None

Charge storage

(Secondary

side)

None

Switch on

<50 ms

Switch off

<50 ms

Switch off

(Emergency

stop)

<10 ms

Note 2

The main conversion transformer is designed to dissipate the

internal heating energy of providing 5 kVA into a direct secondary

side short circuit.
