RootWave Pro User Guide

Troubleshooting

If this section cannot solve your problem, or if you’re unsure, please

contact your RootWave Pro supplier.

 For contact information, see section ‘Contact details’ on page 3.

RootWave Pro does not activate

Cause

⚫ Power

⚫ System

⚫ Ready

⚫ Live

⚫ Fault

Solution

Generator has

tripped or

output is off

Restart generator

Check output is on

 For more

information see

page 70

230 V, 25 A, gG

inlet fuse has

blown.

Turn the power

isolator switch on

the Power Module

to ‘Off’ and turn

off the generator.

Change fuse on

the Power Module.

 For more

information see

page 64.
