RootWave Pro User Guide

Temperature

Ambient /

operational range

+0 Degrees Centigrade to +40 Degrees

Centigrade.

Ambient / storage

-20 Degrees Centigrade to +60 Degrees

Centigrade.

Temperature cutout

+150 Degrees Centigrade (+/- 5%).

See "Note 3".

Note 3

Measured inside the transformer core.

IP ratings

System operational

IP40

Single system

components

IP20

See "Note 4"

Note 4

IP rating limited by connector ports.

IP rating of connectors increased through connection of mating part

(cap or cable).
