Table 7 Treatment Lance trigger positions

Position

Action

Purpose

Either or both triggers

are fully released

The Treatment Lance is inactive

Both triggers are

pressed to the middle

position

The Treatment Lance is active

(if all other systems are on and

reset button has been pressed)

Either or both triggers

are fully pressed

Safe Stop is activated and the

Treatment Lance cannot be

activated until it is reset
