Table 2 Power Module controls
1
Socket for
generator
cable
Connects generator to provide input power for
system.
 See ‘Specifications’ on page 74.
2
Power
isolator
switch
Rotating dial for switching Power Module on and
off. A padlock and key are provided to control
access to the power isolator switch.
3
Emergency
stop button
Push in to deactivate the Power Module in an
emergency. Twist to release.
4
Socket for
Safety Earth
Connects Power Module to Safety Earth. With
dust cover.
5
Socket for
Treatment
Cable
Connects Power Module to Treatment Return
(which in turn connects to Treatment Lance). Only
use Short Treatment Cable. With dust cover.
6
Power light
Lights up when connected to the generator and
the generator output is ON (green).
7
System light
Lights up when the power isolator switch is
rotated to the ON position (green).
8
Ready light
Lights up when Treatment Return and Safety
Earth are attached and inserted into ground, and
Emergency Stop is not activated (green).
9
Live light
Lights up when the Treatment Lance has been
reset and can be activated (amber). Flashes when
Treatment Lance needs to be reset.
10
Fault light
If the Power Module overheats the Power Module
is automatically deactivated and the fault lamp
lights up (red).
11
24V fuse
Caps for accessing internal fuses.
 See section ‘Changing the fuse’ on page 64 for
more information including safety information
12
230V fuse
