A-13
MODEL 2700 APPENDIX A
SERIAL COMMUNICATIONS PROTOCOL
Command name Cmd (hex) Cmd (dec) Cmd (dec) Cmd (hex) Command name
Read EEPROM 64 100 99 63 Update EEPROM
Read RAM 6E 110 100 64 Read EEPROM
Reset Instrument 72 114 108 6C Send Measurement
Send Base Address 76 118 110 6E Read RAM
Send Instrument Status 73 115 111 6F Write RAM
Send Measurement 6C 108 114 72 Reset Instrument
Send Scale Factors 77 119 115 73 Send Instrument Status
Send Sensor Status 74 116 116 74 Send Sensor Status
Send Software Version 75 117 117 75 Send Software Version
Send Units Text 78 120 118 76 Send Base Address
Update EEPROM 63 99 119 77 Send Scale Factors
Write RAM 6F 111 120 78 Send Units Text
TABLE 1. Commands
