4-1
MODEL 2700 SECTION 4.0
CONFIGURATION
SECTION 4.0
CONFIGURATION
TABLE 4-1. Factory And User Settings
ITEMS CHOICES RANGE DEFAULT USER SETTING
1. SENSORS (Sec. 4.3)
Conductivity K=0.01
(Note: K = Cell Constant)
Units See Table 4-2 µS/cm _______________
Liquid Type PURE WATER 0-50 µS/cm PURE WATER _______________
WATER 0-50 µS/cm
NaCl 0-50 µS/cm
CATION 0-50 µS/cm
Conductivity K=1.0
Units See Table 4-2 mS/cm _______________
Liquid Type WATER 0-10,000 µS/cm WATER _______________
NaCl 0-10,000 µS/cm
Conductivity 4 Electrode K=.85
Units See Table 4-2 % CONC _______________
Liquid Type NaOH 0-15%, .5-410 mS/cm NaOH _______________
WATER .5-250 mS/cm
H
2
SO
4
0-27%, .5-810 mS/cm
HCl 0-16%, .5-840 mS/cm
NaCl 0-27%, .5-250 mS/cm
pH
Units pH -4 - 16 pH _______________
mV (ORP) -1400 - 1400
2. ANALYZER (Factory settings dependent upon the type of sensor at address #1.)
Conductivity - K=0.01
Alarm 1 (Sec. 4.5) Any Sensor 1 - 8 Address #1 _______________
Alarm point (Sec. 4.5) 10 µS/cm _______________
Deadband Point (Sec. 4.5) 9 µS/cm _______________
Alarm 2 (Sec. 4.5) Any Sensor 1 - 8 Address #1 _______________
Alarm Point (Sec. 4.5) 1 µS/cm _______________
Deadband Point (Sec. 4.5) 2 µS/cm _______________
Table 4-1 is continued on page 4-2
4.1 GENERAL
This section details all of the items available in the
Menu mode to configure the analyzer to a specific
application.
Since each application may be different, no attempt has
been made to describe what each parameter should be
set for, only how to set the parameter.
However, the configuration worksheet included as Table
4-1 should be completed before proceeding with any
configuration. This table briefly describes the parame-
ters available for changing, their factory settings, and
lists the section to refer to when changes need to be
made to the setting.
