TABLE 8. AdrOffsets
A-22
MODEL 2700 APPENDIX A
SERIAL COMMUNICATIONS PROTOCOL
Offset Data
Base Adr Type Data Value Bytes
Alarm Source 0 1
Alarm Mode 2 1
Alarm Type 3 1
Alarm Set Point 4 4
Alarm Deadband 8 4
Display Display Source 0 1
Display Display Units 2 1
Dual Data Dual Measurement 0 4
Output Source 0 1
Output Mode 2 1
Output Type 3 1
Output Low Range 4 4
Output High Range 8 4
Output User Gain Factor 12 4
Output Measurement Intercept Factor 20 4
Output Measurement Slope Factor 24 4
Output Intercept Cal Factor 28 4
Output Slope Cal Factor 32 4
Snr Cal Cal 0 2
Snr Config Type 0 1
Snr Config Units 1 1
Snr Config Compensation 2 1
Snr Config Serial Number MSB 3 1
Snr Config Serial Number LSB 4 1
Snr Data Primary Measurement 0 4
Snr Data Secondary Measurement 4 4
System Sensor Count 0 1
System Option Card 1 1
System Serial Number 2 3
System High Level Password MSB 11 1
System High Level Password LSB 12 1
System Low Level Password MSB 13 1
System Low Level Password LSB 14 1
