Rosemount 2700 - Page 79

A-45
MODEL 2700 APPENDIX A
MODBUS PROTOCOL
UNITS VALUE TEMPERATURE VALUE UNITS TEMPERATURE
COMPENSATED COMPENSATED
%CONC 24 YES 0 µS/m YES
DegC 39 N/A 1 µS/m Raw NO
Kohm-cm 16 YES 2 µS/cm YES
Kohm-cm Raw 17 NO 3 µ S/cm Raw NO
Kohm-m 18 YES 4 mS/m YES
Kohm-m Raw 19 NO 5 mS/m Raw NO
Mohm-cm 12 YES 6 mS/cm YES
Mohm-cm Raw 13 NO 7 mS/cm Raw NO
Mohm-m 14 YES 8 S/cm YES
Mohm-m Raw 15 NO 9 S/cm Raw NO
mS/cm 6 YES 10 S/m YES
mS/cm Raw 7 NO 11 S/m Raw NO
mS/m 4 YES 12 Mohm-cm YES
mS/m Raw 5 NO 13 Mohm-cm Raw NO
mV-ORP 35 NO 14 Mohm-m YES
ohm-cm 22 YES 15 Mohm-m Raw NO
ohm-cm Raw 23 NO 16 Kohm-cm YES
ohm-m 20 YES 17 Kohm-cm Raw NO
ohm-m Raw 21 NO 18 Kohm-m YES
pH 34 YES 19 Kohm-m Raw NO
ppm-TDS 28 YES 20 ohm-m YES
ppt-TDS 30 YES 21 ohm-m Raw NO
S/cm 8 YES 22 ohm-cm YES
S/cm Raw 9 NO 23 ohm-cm Raw NO
S/m 10 YES 24 %CONC YES
S/m Raw 11 NO 28 ppm-TDS YES
µS/cm 2 YES 30 ppt-TDS YES
µS/cm Raw 3 NO 34 pH YES
µS/m 0 YES 35 mV-ORP NO
µS/m Raw 1 NO 39 DegC N/A
Dual Measurement
UNITS VALUE
DIFF 0
RATIO 1
%PASS 2
%REJECT 3
SENSOR TYPE VALUE
K.01 0
K1.0 2
K.85 4
pH 5
TABLE 17. Unit
