Platinum Plus
41
Relay Assignments
Relay Function
1 01 Heat 1
2 02 Heat 2
3 03 Heat 3
4 04 Heat 4
5 05 Heat 5
6 53 Exhaust Fan 1
7 55 Exhaust Fan 2
8 57 Exhaust Fan 3
9 54 Exhaust Fan 4
10
11 33 Tunnel Fan 1
12 34 Tunnel Fan 2
13 35 Tunnel Fan 3
14 36 Tunnel Fan 4
15 37 Tunnel Fan 5
16 38 Tunnel Fan 6
17 39 Tunnel Fan 7
18 40 Tunnel Fan 8
19 41 Tunnel Fan 9
20 98 VFS (Fail Safe), Extra System 1
21 104 Side Inlets Open
22 105 Side Inlets Close
23 102 Tunnel Inlet Curtain Open
24 103 Tunnel Inlet Curtain Close
25 108 Cross Fill Auger 1
26 106 Feeder
27 106 Feeder
28 78 Cool Cell Pump 1
29 79 Cool Cell Pump 2
30 107 Lights
31 107 Lights
32
33
34
35
36
37
38
39
40
Note: Under Help | Set you can reverse up to 5 relays, and
select normal or power saving operation modes. By default,
the Platinum Plus uses power saving mode for the relays to
reduce heat inside the controller.
