Platinum Plus
55
the Set option. Note that the pressure can ramp according to outside temperature in side
ventilation mode.
Pressure
Side
Pressure at Low Temperature 0.100
Pressure at High Temperature 0.050
Low Alarm 0.020
High Alarm 0.180
Band 0.040
Tunnel
Pressure 0.060
Low Alarm 0.015
High Alarm 0.180
Band 0.040
Help | Set Parameters
Wind Gust Delay Time (sec): 20 Pressure During Tunnel?: Yes
Incoming Air Low Temp: 60.0ºF Incoming Air High Temp: 80.0ºF
Emergency Pressure Delay: 60 sec Curtain Position in Emergency: 100
Low Pr. Alarm Min Lev (Side): 0 Low Pr. Alarm Min Lev (Tunnel): 0
Time to Produce Pressure (Seconds): 10
Set Parameters:
1. Wind Gust Delay Time (sec): length of time to delay before making pressure
adjustments to unexpected pressure changes. Note that the Platinum Plus uses zero
delay when its actions result in pressure changes.
2. Pressure During Tunnel: select whether to use pressure settings in tunnel.
3. Incoming Air Low Temp: outside temperature for low temperature pressure setting.
4. Incoming Air High Temp: outside temperature for high temperature pressure setting.
5. Emergency Pressure Delay (seconds)
: this is the length of time the Platinum Plus
waits before taking emergency action in the event static pressure remains above the
high pressure alarm setting. By default it opens all air sources to save the birds. Use
Alarm Reset under the Management Menu to restore normal operation.
6. Curtain Position in Emergency
: during cold weather you may wish to restrict how
far the curtains (either tunnel or conventional) open in emergency situations.
7. Minimum Curtain Level in Tunnel
: the tunnel curtain must open at least this far,
even if pressure is low, when in tunnel. If tunnel pressure is not used, then this is the
amount the tunnel curtain opens on switch to tunnel.
8. Low Pressure Alarm Minimum Level (Side)
: ignore low pressure alarms below this
ventilation level.
9. Low Pressure Alarm Minimum Level (Tunnel): ignore low pressure alarms below
this ventilation level while in tunnel.
10. Time to Produce Pressure: the Platinum Plus requires pressure to stabilize during its
learning phase while it learns how much to advance inlet opening ahead of minimum
ventilation fan operation. Many houses require stabilization times of 10 seconds or
greater. If your inlets are not opening before the fans run, then increasing this time to
20 seconds usually makes things work.
