Actuator Input Output Signals
Publication PUB089-005-00_0618 45 of 116
Index 5: DEVICE_STATUS2
Bit
Title
Description
0
No response from Actuator controller
There is a communications failure between the Fieldbus
and actuator
1
2
3
4
Checksum error
Checksum error on the FIC
5
6
7
8
TB in OOS mode
Transducer block is in OOS mode
9
10
11
Index 6: DEVICE_STATUS3
Bit
Title
Description
0
AI 1 in OOS mode
AI 1 is in Out of Service mode
1
AI 1 in MAN mode
AI 1 is in Manual mode
2
AI 1 in Simulate active
AI 1 simulation is active
3
4
AI 2 in OOS mode
AI 2 is in Out of Service mode
5
AI 2 in MAN mode
AI 2 is in Manual mode
6
AI 2 in Simulate active
AI 2 simulation is active
7
8
DI 1 in OOS mode
DI 1 is in Out of Service mode
9
DI 1 in MAN mode
DI 1 is in Manual mode
10
DI 1 in Simulate active
DI 1 simulation is active
11
12
DI 2 in OOS mode
DI 2 is in Out of Service mode
13
DI 2 in MAN mode
DI 2 is in Manual mode
14
DI 2 in Simulate active
DI 2 simulation is active
15
16
DI 3 in OOS mode
DI 3 is in Out of Service mode
17
DI 3 in MAN mode
DI 3 is in Manual mode
18
DI 3 in Simulate active
DI 3 simulation is active
19
20
DI 4 in OOS mode
DI 4 is in Out of Service mode
21
DI 4 in MAN mode
DI 4 is in Manual mode
22
DI 4 in Simulate active
DI 4 simulation is active
23
24
DI 5 in OOS mode
DI 5 is in Out of Service mode
25
DI 5 in MAN mode
DI 5 is in Manual mode
26
DI 5 in Simulate active
DI 5 simulation is active
27
